6000 series "Economical"centrifugal fans / 6200 Ultrafoil Square body fan
6200 Ultrafoil : an economical, square body fan.
with backward curved airfoil wheel blades. Intended
for use in commercial & light industrial applications.
Can be made of steel, stainless steel and aluminum.
Arrangements 1, 3, 4 & 9 are available. Class 1 to 3.
Fan wheel sizes 12-1/2" dia to 36-1/2" dia. SISW & DIDW
Performance range 1500 cfm at 1" spwg to
75,000 cfm at 13" and limited to 300 DegF/ 149C
with standard construction, for temperatures
above 300 DegF/ 149C consult Sheldons Engineering
Dept. email: engineer@sheldonsengineering.com
6200 catalogue.pdf
|
